KDD for Business Intelligence
Rafi Ahmad Khan, University of Kashmir, Srinagar, India
ABSTRACT:
Emergence of knowledge based economy has posed serious challenges to companies. Intelligent organizations recognize that knowledge is an intellectual asset that grow over time and when harnessed effectively, can sustain competition and innovation. Organizations can use IT for leveraging the entire organization’s intellectual resources for great financial impact. Business Intelligence (BI) along with KDD (Knowledge Discovery in Databases) plays a pivotal role in leveraging the intellectual assets of companies by creating, storing and sharing that knowledge for effective decision making. Companies are now realizing the potential payoffs of KDD applications along with BI. Consequently, BI is spreading its wings to cover small, medium and large companies. This paper explores the concepts of BI, KDD, process of knowledge discovery, key levers of knowledge strategy and benefits of BI.
Keywords: Business intelligence, Knowledge discovery in databases, KDD, Data
mining, OLAP
Introduction
Over the past few decades, the
industrialized economy has been going through a transformation from being based
on natural resources to being based on intellectual assets (Alavi, 2000; Tseng & James Goo, 2005). The knowledge based economy is a reality (Godin, 2006). Rapid changes in the business environment cannot be handled in
traditional ways as companies are expanding and are much larger today than they
used to be, fueling the need for better tools for collaboration, communication
and knowledge sharing. Competing in the
globalized economy and markets requires quick and effective response to
customer needs and problems. For companies spread over wide geographical areas
and virtual organizations, managing knowledge is critical for providing
services. Companies must develop the strategies to sustain competitive
advantage by leveraging their intellectual assets for optimal performance (Skyrme, may, 2002; Agrawal et al, 1996).
Knowledge And
Business Intelligence (BI)
Presently, information technology
assumes a major role in business, because of it pivotal role in building
business intelligence in enterprises. Business Intelligence (BI) is a
broad category of applications and technologies for gathering,
analyzing, and providing access to huge data stored within the company’s
database. The term intelligence in Business Intelligence (BI) is closely
related with knowledge. Knowledge refers to stored information or models used
by a person or machine to interpret, predict and appropriately respond to the
outside world (Fischler & Firschein, 1987). In the IT context knowledge is very
distinct from data and information. Whereas data are facts, measurements and
statistics, information is organized or processed data that is timely and
accurate (Hoffer et al, 2002; Kankanhalli
& Tan, 2005). Knowledge is
information that is contextual, relevant and actionable. Having knowledge
implies that it can be exercised to solve a problem. While data, information
and knowledge may all be viewed as assets of an organization, knowledge
provides higher level of meaning about data and information.
Intelligence is often defined as
the general mental ability to learn (acquire knowledge) and how to apply
knowledge. Intelligence encompasses cognition. Cognition is the method by which
people assimilate and integrate knowledge, while intelligence is both the
assimilation of knowledge as well as the ability to apply such knowledge. Thus
knowledge is imperative for BI system in an organization. A BI system must have
capability to manage knowledge, store it in a knowledge repository and tools
that can apply that knowledge for better decision making. Companies are adopting Business Intelligence
(BI) systems and tools because of their capability to learn from the
past and forecast the future.
Knowledge in an enterprise may
originate from many different sources. They include information
systems, reports, Internet, corporate databases, customers, suppliers
or government agencies. Knowledge of the employees is an
absolute source of information. It results from their experience and
intuition.
Polanyi (1958) first conceptualized the difference between an organizations explicit
and implicit knowledge. Explicit knowledge deals with more objective, rational,
and technical knowledge (e.g., data, policies, procedures, software and
documents). It is leaky knowledge as it can be readily documented (Alavi, 2000). Tacit knowledge is usually in the domain of subjective, cognitive and
experiential learning; it is highly personal and difficult to formalize. It is
also referred to as embedded knowledge (Tuggle
& Goldfinger, 2004) as it
typically involves expertise, know-how, trade secrets, skill set, understanding
and learning, hence difficult to document. When people leave the organization,
they take their knowledge with them. Consequently it has become vital for
organizations to retain the valuable know-how that can so easily and quickly
leave an organization. Organizations now recognize the need to capture and
integrate both types of knowledge. BI is the process that transforms data into
information and then into knowledge (Golfarelli et al, 2004). It has proven to be successful
not only in analyzing data, but also in discovering knowledge by uncovering
trends and patterns that are hidden deep within datasets. These hidden
trends and patterns can be investigated to forecast future directions (Watson & Wixom, 2007). BI is spreading its wings to cover small, medium and large
companies, more and more analytical tools are penetrating the market to do
any kind of analysis and help to make informed decision making (Khan
& Quadri, 2012).
In business management term BI
is used to be described as applications and technologies which are used to
gather, provide access to and analyze data and information about an
enterprise, in order to help them make better informed
business decisions (Reinschmidt
& Francoise, 2002; Moss & Atre, 2003; Wu et al, 2007; Jonathan, 2000). Ranjan
(2008) argues that BI is the
conscious, methodical transformation of data from any and all data sources into
new forms to provide information that is business-driven and results-oriented.
As per (Pirttimäki, 2004), BI process concept is understood as a
continuous and systematic method of action by which an organization gathers,
analyses, and disseminates relevant business information to business
activities. Cui et al (2007) argues that BI is the way and method of improving
business performance by providing powerful assistance to executive decision
maker which enables them to have actionable information at hand. BI tools are
viewed as technology that enhances the efficiency of business operation by
providing an increased value to the enterprise information and hence the way
this information is utilized. According to Zeng et al (2006) BI is
“The process of collection, treatment and diffusion of information that has an
objective, the reduction of uncertainty in the making of all strategic
decisions.”
BI can be utilized to view not
only current action, but also suggest the most suitable direction an
organization should take, consequently BI can be an invaluable tool for
decision–makers and managers (Dhar &
Stein, 1997). However, the
success of BI tools depends on the quality of data it uses. Therefore quality
data, its transformation to information and extraction of knowledge from it,
are essential to a successful BI implementation. As a result, it is vital
to explore the techniques that can be implemented to select and analyze
organizational data. Knowledge Discovery in Databases (KDD) is one
process, which can be explored to ensure the highest quality of data is
available for BI applications.
Knowledge Discovery In Databases (KDD)
Database and their tools provide
the necessary infrastructure to store, access, and manipulate
data. Data warehousing, a recently popularized term, refers to the
current business trend of collecting and cleaning transactional data to make
them available for online analysis and decision support. A popular
approach for analysis of data warehouses is called online
analytical processing (OLAP) (Agrawal et al, 1996). OLAP tools focus on providing multidimensional data analysis,
which is superior to SQL (a standard data manipulation language) in
computing summaries and breakdowns along many dimensions. While
current OLAP tools are semi-automated and target interactive
data analysis, they will also include more automated discovery
components in the near future.
KDD is the automated process that
relies on methods from various fields like pattern recognition, applied
statistics, machine learning, neural networks etc. to find patterns from
data in the data mining step of the KDD process. The phrase ‘Knowledge Discovery in
Databases’ was coined at the first KDD workshop in 1989 by Piatetsky-Shapiro, who emphasized that knowledge is
the end product of a data-driven discovery (Piatetsky-Shapiro & Frawley, 1991). KDD can be defined as the non-trivial extraction of implicit,
previously unknown, and potentially useful information from databases. The
declining cost of storage technology and advances in data communication
technologies have enabled the companies to capture and store data with ease (Fayyad, 1996: Witten & Frank, 2005). This growth, by far exceeds human
capacities to analyze the databases in order to find hidden rules
or patterns within the data. Therefore, knowledge discovery becomes more
and more important in databases (Lazcorreta
et al, 2008).
Knowledge discovery is
multidisciplinary area of research (Wu,
2004) and is apparent in
almost any field; science; marketing; finance; health care; retail etc.
The traditional method of turning data into knowledge relies upon manual
analysis and interpretation (Witten &
Frank, 2005), but as the volume
of data captured increases, manual data analysis has become unrealistic in
many domains. Therefore, the requirement to scale up human analysis
capabilities in order to analyze the large volumes of data became imperative.
KDD is concerned with the
development of methods and techniques that helps in the analysis and
interpretation of huge volumes of data. At the core of the KDD process is
the application of specific data mining methods for pattern discovery and extraction
(Han & Kamber, 2006; Geist, 2002).
Process Of
Knowledge Discovery
The KDD process model is an
interactive, iterative, procedure that attempts to extract
implicit, previously unknown and potentially useful knowledge from data
through a scientific method. KDD process model can be divided into a
number of steps.
There are a number of variants
of KDD process, such as those that have been published by Adriaans & Zantinge (1996), Brachman & Anand
(1996), and Han & Kamber (2006) in addition to others, however, all variants of the KDD process
remain close to as described by (Fayyad,
1996) and supported by (Roiger & Geatz, 2003). It is a well-accepted approach of the KDD
process, consisting of several stages as depicted in Figure 1. The various
stages are:
Data Selection: The goal of this stage is the extraction of relevant data from huge
data stored in operational database, data warehouse and data marts that is
relevant to the data mining analysis.
Data Preprocessing: This stage of KDD is concerned with data cleansing and preparation
tasks that are essential to ensure correct results. Eliminating missing values
in the data, ensuring that coded values have a uniform meaning and ensuring
that no spurious data values exist are typical activities that occur during
this stage.
Data Transformation: This stage is aimed at transforming the data into a two-dimensional
table and eliminating unwanted fields so the results are valid.
Data Mining: The goal of the data mining stage is to analyze the data by a suitable
set of algorithms in order to discover meaningful patterns and rules and
produce predictive models. This is the main element of the KDD cycle.
Interpretation and Evaluation: Using discovered knowledge includes incorporating this knowledge into the performance system, taking actions based on the knowledge, or simply documenting it and reporting it to interested parties.
Figure
1: Knowledge Discovery Process
While data mining algorithms have the potential to yield an unlimited number of patterns hidden in the data, several of these may not be meaningful or useful. This final phase is aimed at selecting those models that are valid and worthwhile for making future business decisions. It is possible to return to any of the previous stages at this point, should the need arise. Furthermore, the evaluation can also involve visualization of the extracted patterns and models or visualization of the data given the extracted models. The result of this process is newly acquired knowledge formerly hidden in the data. There are generally five types of information that can be obtained through data mining which include (Turban & Aronson, 2001):
·
Classification: It infers the defining
characteristics of certain group (e.g., customers who have been lost to
competitors).
·
Clustering: It identifies groups of items that share a specific
characteristics (clustering differs from classification in that no predefining
characteristics is given).
· Association: It identifies relationships between events that occur at one time (e.g., the contents of a shopping basket).
· Sequencing: It is similar to association, except that the relationship exists over a period of time (e.g., repeat to a supermarket or use of a financial planning product).
· Forecasting: It estimates future values based on patterns within large sets of data(e.g., demand forecasting)
Data Mining constitutes one step in the KDD process. It is in data mining step that the actual search for patterns of interest is performed. It is important at this stage to choose the appropriate data mining algorithm (like neural networks, linear/logistic regression, association rules, etc.) for the data mining task. The data mining task itself can be a classification task, linear regression analysis, rule formation, or cluster analysis (Imberman & Susan, Dec 2001).
The extracted information/knowledge obtained by applying BI tools must be stored in knowledge repository for future use and sharing within the organization.
Key Levers Of
Knowledge Strategy
Companies are increasingly recognizing the contribution of knowledge in the
form of intellectual capital or knowledge base of the firm and the value that can be derived from it. Skyrme (2002) has given seven key levers that will
have the maximum impact on a knowledge-based strategy. Briefly the seven levers are:
·
Customer
knowledge: repeatedly cited in surveys as the most important knowledge an
organization needs to capture and exploit; Business Intelligence (BI)
helps in retaining existing and identifying potential customers and
suppliers.
·
Knowledge-enhanced
products and services: adding
value by surrounding the product with additional information, such as personal
preferences when booking travel; BI helps to add value by using the
captured knowledge and collaboration.
·
Knowledge
in people: people-focused programs aim to continually improve
workforce skills through development: BI helps in skills development
through collaboration technologies and eLearning.
·
Organizational
memory: knowing what an organization knows, over space and time e.g.
sharing best practice or recording lessons learned: BI through collaboration
technology helps in sharing practices.
·
Knowledge
in processes: capturing the knowledge of the best professionals and
embedding their good practices into the recommended procedures: BI helps to
capture implicit knowledge from experts.
·
Knowledge
in relationships: creating forums and other mechanisms to have
intimate sharing of knowledge with suppliers, customers and partners;
sharing of knowledge is a common practice BI
·
Knowledge
assets – the intellectual capital focus; BI not only focuses on the
intellectual capital of company but also assists to perceiving
corporate competencies of competitors.
Benefits
The major benefit of BI with knowledge discovery tools is the ability to provide accurate information when needed, including real-time view of corporate performance. Thomson (2004) on the basis of survey reported the following major benefits of BI:
· Faster, more accurate reporting (81 percent)
· Improved decision making(78 percent)
· Improved customer services (56 percent)
· Increased revenue (49 percent)
· Many of the benefits of BI are intangible. That’s why, according to Eckerson (2003), so many executives do not insist on rigorous cost justification of BI Projects.
Conclusion
The continuous shift towards a knowledge-based economy has brought to
the fore the issue of how knowledge is created, assimilated and used to
obtain economic returns. Knowledge embodied in intellectual assets (e.g. human capital, R&D,
patents, software, documents etc.) is becoming essential for organizations
economic performance and growth. In this new environment, companies need to
be able to earn economic returns from both developing and using
intellectual assets. KDD is a new generation of computational
techniques and tools that support the extraction of useful knowledge
from the rapidly growing volumes of data. The organizations are now
realizing the potential payoffs of KDD applications along with BI. By
bringing together a set of diverse fields, KDD along with BI creates
fertile ground for the development of new tools and techniques for
managing, analyzing, and creating value from the flood of data facing
modern business world. It is the responsibility of researchers,
academicians and practitioners in this field to ensure that users understand
the potential contributions of KDD and BI for creating value and gaining
competitive advantage.
References
Adriaans, P., & Zantinge, D. (1996). Data Mining. Harrow, England:
Addison-Wesley.
Agrawal, R., Mannila, H., Srikant, R.,
Toivonen, H., & Verkamo, I. (1996). Fast discovery of association rules. In
U. Fayyad, Piatetsky-Shapiro, P. Smyth, & R. Uthurusamy, In Advances in Knowledge Discovery and Data
Mining. London: AAAI/MIT Press.
Alavi, M. (2000). Managing Organizational
Knowledge. In R. ZMUD, In Framing the
Domain of IT Management. Pinaflex Educational Resources.
Brachman, R., & Anand, T. (1996). The
process of knowledge discovery in databases: a human-centered approach. In Advances in Knowledge Discovery and Data
Mining (pp. 37–58). AAAI Press.
Cui, Z., Damiani, E., & Leida, M. (2007).
Benefits of Ontologies in Real Time Data Access. Digital Ecosystems and Technologies Conference, DEST '07.pp. 392-397.
Dhar, V., & Stein, R. (1997). Intelligent decision support methods.
Upper Saddle River, NJ: Prentice Hall.
Eckerson, W. (2003). smart Companies in 21st Century: The Secrets of Creating sucessful BI
solutions. Seatle: The Data Warehousing Institute.
Fayyad, U. M. (1996). Data Mining and
Knowledge Discovery: Making Sense Out of Data. IEEE Expert(11(5)), 20–25.
Fischler, M. A., & Firschein, O. (1987). Intelligence: The Eye, The Brain anf The
Computer. Addison-Wesley.
Geist, I. (2002). A framework for data mining
and KDD. 2002 ACM symposium on applied
computing. Madrid, Spain.
Godin, B. (2006). The Knowledge-Based
Economy:Conceptual Framework or Buzzword? The
Journal of Technology Transfer, 17-30.
Golfarelli, M., Rizzi, S., & Cella, I.
(2004). Beyond data warehousing: what’s next in business intelligence? DOLAP ’04: Proceedings of the 7th ACM
international workshop on Data warehousing and OLAP. New York.
Han, J., & Kamber, M. (2006). Data Mining: Concepts and Techniques, Second
Edition. Morgan Kaufmann.
Hoffer, J., Prescort, M., & McFadden, F.
(2002). Modern Database Management 6th
ed. Prentice Hall.
Imberman, & Susan, P. (Dec 2001).
Effective Use Of The KDD Process And Data Mining For Computer Performance
Professionals. Proceedings of CMG 2001.
Jonathan, W. (2000). Business Intelligence:
What is Business Intelligence? DM Review.
Kankanhalli, A., & Tan, B. C. (2005).
Knowledge Management Metrics: A Review and Directions for Future Research. International Journal of Knowledge Management
vol, 1(2), 20-32.
Khan, R. A., & Quadri, S. M. (2012).
Business Intelligence: An Integrated Approach. The Business Intelligence Journal (BIJ), 5(1), 64-70.
Lazcorreta, E., Botella, F., &
Fernández-Caballero, A. (2008). Towards Personalised Recommendation by Two-Step
Modified Apriori Data Mining Algorithm. Expert
Systems with Applications, 35(3), 1422-1429.
Moss, L., & Atre, S. (2003). Business Intelligence Roadmap: The Complete
Lifecycle for Decision-Support Applications. Boston: Addison-Wesley.
Piatetsky-Shapiro, G., & Frawley, W.
(1991). Knowledge Discovery in Databases.
Menlo Park, Calif: AAAI Press.
Pirttimäki, V. (2004). The Roles of Internal
and External Information in Business Intelligence. Frontiers of E-Business Research.
Polanyi, M. (1958). Personal Knowledge: Towards a Post-Critical Philosophy. Chicago:
University of Chicago Press.
Ranjan, J. (2008). Business justification
with business intelligence. The Journal
of Information and Knowledge Management Systems, 38(4), 461-475.
Reinschmidt, J., & Francoise, A. (2002). Business Intelligence Certification Guide.
IBM, International Technical Support Organization.
Roiger, R. J., & Geatz, M. W. (2003). Data Mining a Tutorial Based Primer. San
Francisco: Addison-Wesley.
Skyrme, D. J. (2002). Business value from
knowledge management. Conference
Mobilising Knowledge for Business Performance. London.
Thomson, O. (2004, Oct). siness Intelligence Success, Lessons learned. Retrieved from
www.technologyevaluation.com
Tseng, C. Y., & James Goo, Y. J. (2005).
Intellectual capital and corporate value in an emerging economy: empirical
study of Taiwanese manufacturers. R&D
Management, 187–201.
Tuggle, F. D., & Goldfinger, W. E.
(2004). A Methodology for Mining Embedded Knowledge from Process Maps. Human Systems Management, 23(1).
Turban, E., & Aronson, J. E. (2001). Decision Support Systems & Intelligent
Systems, 2nd ed. India: Pearson Education Inc .
Watson , H. J., & Wixom, B. (2007). The
Current State of Business Intelligence. IEEE
Computer, 40, pp. 96-99.
Witten, I., & Frank, E. (2005). Data Mining: Practical Machine Learning
Tools and Techniques. San Francisco: Morgan Kaufmann.
Wu, L., Barash, G., & Bartolini, C.
(2007). A Service-oriented Architecture for Business Intelligence. Service-Oriented Computing and Applications
SOCA '07, IEEE International Conference. 279-285.
Wu, X. (2004). Data Mining: Artificial
Intelligence in Data Analysis. Proceedings
of IEEE/WIC/ACM International Conference on Intelligent Agent Technology.
Zeng, L., Xu, L., Shi, Z., Wang, M., &
Wu, W. (October 8-11, 2006). Techniques, process, and enterprise solutions of
business intelligence. IEEE Conference on
Systems, Man, and cybernetics, 6,
p. 4722. Taipei, Taiwan.
